Camera:
- Image Sensor1; MP CMOS
- Signal System; PAL/NTSC
- Min. Illumination; 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR
- Shutter Time; PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
- Day & Night; IR Cut Filter
- Angle Adjustment; Pan: 0° to 350°, Tilt: 0° to 70°, Rotation: 0° to 350°
- Max. Resolution; 1280 (H) × 720 (V)
Lens:
- Lens Type; Fixed focal lens, 2.8 mm, 3.6 mm, and 6 mm optional
- Focal Length & FOV; Field of view: 70.9°(3.6 mm), 92°(2.8 mm), 56.7°(6 mm)
- Lens Mount; M12
Illuminator:
- Supplement Light Type; IR
- Supplement Light Range; Up to 20 m
Image:
- Frame Rate; 720p@25fps/720p@30fps
- SNR; >62 dB
Interface:
- Video Output; 1 HD analog output
General:
- Power; 12 VDC±15%, max. 4 W
- Dimension; Φ 98 mm × 65.4 mm (Φ 3.86" × 2.57")
- Weight; Approx. 240 g (0.53 lb.)
- Operating Condition; -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensing)
